Datasheet: Typhoon Roller Mills
|
|
Model: Typhoon Pneumatic (Double and single) Roller Stands |
|
|
|
Description & Use
|
Industrial Roller mills in single stand(4 rolls) and double stand(8 rolls) execution with 250 diameter rolls. Rolls are pneumatically engaged and disengaged with feeder rolls |
|
Motor size |
11-37.5kW |
|
Rpm |
650 RPM |
All motors are 3 phase 380V Volt, 50 Hz unless otherwise indicated
Dimension & Mass(Based on single stand)
|
Length |
1880 mm |
|
Width |
1537 mm |
|
Height |
2394 mm |
Optional items excluded unless specifically mentioned:
|
Product Name |
|
Colour |
|
Timebelts |
|
Feeding rolls automation |
Number of rollers
|
Stand |
Rollers |
Pairs |
|
Double stand |
8 |
4 |
|
Single stand |
4 |
2 |
|
Speed differential |
1: 1.25 and 1: 2.5 or as required |
|
Drive |
Gear standard or timing belt optional |
|
Control |
PLC or PC or manual |
|
Main pressure |
6 bar |
|
Mass - double stand |
5,800kg (1,000mm) or 6,200kg (1,250mm) |
|
Mass - single stand |
2,800kg (800mm) / 3,200kg (1,000mm) / 37,00kg (1,250mm) |
|
Volume crated |
9.5m3 & 10.5M3 (double 1000 / 1250) 6.3m3 / 7m3 / 7.8 m3 (single 800/1000/1250) |
Additional Information
|
Sizes of rollers: |
|
250mm x 1000mm |
|
250mm x 1250mm |
|
250mm x 800mm (single stands only) |
Technical specifications may be altered without notice. All capacities
shown are indicative only
